Flanged standard type

Standard flanged bearings feature an integrated flange, making installation and alignment simple and straightforward, thereby effectively streamlining the equipment assembly process. They offer excellent overall precision, smooth rotation and stable load-bearing capacity, and boast a robust and durable construction. They are widely used as standard components in general machinery, conveying equipment and automated systems.

Flanged standard type

Product Parameters

Inquiry Bearing Basic Dimensions (mm) Rated Load (kN) Weight
≈kg
Model d D B C Dynamic C0 Static
✉️ F6910-2RS 50 72 12 14540 11710 —
✉️ F6810-2RS 50 65 7 6610 6090 —
✉️ F6809-2RS 45 58 7 6187 5381 45.3
✉️ F6909-2RS 45 68 12 14100 10830 153
✉️ F6808-2RS 40 52 7 4923 4178 38
✉️ F6908-2RS 40 62 12 13678 9968 137
✉️ F6906-2RS 30 47 9 7242 5003 56.6
✉️ F6807-2RS 35 47 7 4729 3821 34.7
✉️ F6907-2RS 35 55 10 10900 7818 92.2
✉️ F6905-2RS 25 42 9 7001 4540 50.2
✉️ F6806-2RS 30 42 7 4538 3402 29.4
✉️ F63806-2RS 30 42 10 4538 3402 39.2
✉️ F6805-2RS 25 37 7 4303 2932 26.1
✉️ F63805-2RS 25 37 10 4303 2932 34.1
✉️ F63804-2RS 20 32 10 4015 2462 26.5
✉️ F6904-2RS 20 37 9 6381 3682 42.8
✉️ F6804-2RS 20 32 7 4015 2462 19.8
✉️ F6803-2RS 17 26 5 2233 1456 8.9
✉️ F63803-2RS 17 26 7 2233 1456 12
✉️ F6903-2RS 17 30 7 4588 2565 21.4
