Standard miniature bearings
Standard miniature bearings feature standardised specifications, compact and precise dimensions, meticulous craftsmanship, uniform clearances and smooth rotation. With their low-wear, low-noise and lightweight design, and a comprehensive range of products, they are widely used in miniature transmission applications such as electronics, electrical appliances, precision instruments, small motors and office equipment.
Product Parameters
| Inquiry | Bearing | Basic Dimensions (mm) | Rated Load (kN) | Weight ≈kg |
|||
|---|---|---|---|---|---|---|---|
| Model | d | D | B | C Dynamic | C0 Static | ||
| ✉️ | 6709-2RS | 45 | 55 | 6 | 2580 | 2397 | 25 |
| ✉️ | 6710-2RS | 50 | 62 | 6 | 2670 | 2640 | 64 |
| ✉️ | 6708-2RS | 40 | 50 | 6 | 2516 | 2233 | 23 |
| ✉️ | 6706-2RS | 30 | 37 | 4 | 1143 | 947 | 9.2 |
| ✉️ | 6707-2RS | 35 | 44 | 5 | 1866 | 1635 | 15 |
| ✉️ | 6703-2RS | 17 | 23 | 4 | 1000 | 658 | 4.4 |
| ✉️ | 6704-2RS | 20 | 27 | 4 | 1402 | 729 | 6.3 |
| ✉️ | 6705-2RS | 25 | 32 | 4 | 1091 | 838 | 7.9 |
| ✉️ | 6701-2RS | 12 | 18 | 4 | 926 | 530 | 3.4 |
| ✉️ | 6702-2RS | 15 | 21 | 4 | 937 | 582 | 3.9 |
| ✉️ | 639-2RS | 9 | 30 | 10 | 5100 | 2390 | 36 |
| ✉️ | 6700-2RS | 10 | 15 | 3 | 855 | 435 | 1.9 |
| ✉️ | 609-2RS | 9 | 24 | 7 | 3350 | 1430 | 14.7 |
| ✉️ | 629-2RS | 9 | 26 | 8 | 4550 | 1970 | 19.3 |
| ✉️ | 699-2RS | 9 | 20 | 6 | 1720 | 840 | 8.33 |
| ✉️ | 689-2RS | 9 | 17 | 4 | 1330 | 665 | 4.43 |
| ✉️ | 608-2RS | 8 | 22 | 7 | 3300 | 1370 | 12.2 |
| ✉️ | 628-2RS | 8 | 24 | 8 | 3350 | 1430 | 17.4 |
| ✉️ | 638-2RS | 8 | 28 | 9 | 4550 | 1970 | 28.6 |
| ✉️ | 688-2RS | 8 | 16 | 4 | 1610 | 710 | 4.02 |
